If you have ever run docker build, docker run, or docker push without thinking too much about what happens underneath, you are not alone. Docker hides an enormous amount of machinery behind a few simple commands. Most developers understand what Docker does — it packages applications into containers — but far fewer understand how it actually does it.

That is exactly what this article covers. We will walk through Docker's internals step by step: how a Dockerfile becomes an image, how image layers are stacked using a union filesystem like OverlayFS, how a container becomes a running process isolated with Linux namespaces and cgroups, how networking reaches the container through the docker0 bridge and iptables, how the Docker daemon and CLI communicate, and how volumes and content-based hashing make everything shareable and persistent.

Table of Contents

The Big Picture: From Dockerfile to Running Container

Docker's core workflow is often summarized in three words: build, ship, run. Internally, each of these stages maps to a very specific piece of machinery:

  1. Build — docker build reads your Dockerfile line by line and produces an image.
  2. Ship — images are pushed to and pulled from a registry, layer by layer, so only what is missing is transferred.
  3. Run — docker run turns an image into a container: a single, isolated process on your host.

The whole flow looks like this:

flowchart TD
    A[Dockerfile] -->|docker build| B[Build Context]
    B --> C[Instruction 1 creates Layer 1]
    C --> D[Instruction 2 creates Layer 2]
    D --> E[... Instruction N creates Layer N]
    E --> F[Image: read-only stacked layers]
    F -->|docker push| G[Registry]
    G -->|docker pull| F
    F -->|docker run| H[Writable layer added on top]
    H --> I[Container = running process]
    I --> J[Isolated by namespaces + cgroups]
    I --> K[Attached to docker0 bridge / iptables]

Each arrow in that diagram is powered by a specific internal component, and the rest of this article explains each one in detail.

Inside docker build: The Build Context

Everything starts when you run docker build. Docker does two things immediately:

  1. It reads the Dockerfile in your project line by line.
  2. It treats your current folder as the build context — the set of files available to the build process.
docker build -t myapp:latest .

The . at the end is the build context. Docker packages that directory (minus anything excluded via a .dockerignore file) and sends it to the daemon so that instructions like COPY can reference files in it.

Note: The build context can be large. Because it is bundled and sent to the Docker daemon on every build, it is good practice to keep the context small and use .dockerignore to exclude caches, logs, and other junk.

Layers: The Foundation of Images

The most important idea in Docker's internals is the layer.

Each line in the Dockerfile creates a new image layer. Consider this example:

FROM node:20-alpine
WORKDIR /app
COPY package.json .
RUN npm install
COPY . .
EXPOSE 3000
CMD ["node", "app.js"]

Each of those instructions produces one layer. The layers are saved as compressed files inside Docker's storage on the host.

Why does this matter? Layers are the reason Docker can:

  • Cache builds — if a layer's inputs have not changed, Docker reuses the cached layer instead of rebuilding it.
  • Share storage — many images that share a common base (like node:20-alpine) share those base layers locally.
  • Transfer efficiently — pushing and pulling happens per layer, not per image.
flowchart LR
    subgraph Image
        L1[Layer 1: FROM node:20-alpine]
        L2[Layer 2: WORKDIR /app]
        L3[Layer 3: COPY package.json]
        L4[Layer 4: RUN npm install]
        L5[Layer 5: COPY . .]
        L6[Layer 6: CMD node app.js]
    end
    L1 --> L2 --> L3 --> L4 --> L5 --> L6

OverlayFS: Stacking Layers into One Filesystem

If an image is just a stack of layers, how does the container see one normal filesystem? The answer is a union filesystem, and the one Docker commonly uses is OverlayFS.

OverlayFS takes all the individual layers and stacks them on top of each other to form a single container filesystem. When a process inside the container reads /etc/hostname, or opens /app/app.js, the union filesystem resolves that path across the whole stack and returns the correct file — as if it were a plain directory.

Container filesystem view (unified)
┌─────────────────────────────────────┐
│  Layer N   (top of stack)           │
│  Layer ...                           │
│  Layer 3   RUN npm install          │
│  Layer 2   COPY package.json        │
│  Layer 1   FROM node:20-alpine      │  ← base layer
└─────────────────────────────────────┘

This stacking is what makes images so cheap to store and instantiate. A single base layer can be shared by hundreds of derived images, because each derived image only stores its own additional layers.

docker run: Adding the Writable Layer

When you run docker run, Docker takes the image and adds a writable layer on top. This new layer is where your container does all its writing — installing files, creating logs, writing temp data.

docker run -d -p 8080:80 --name web myapp:latest

The image layers stay read-only. Only the thin writable layer on top accepts changes. This design gives you two huge benefits:

  • The image is never modified, so it can be reused for thousands of containers without copying.
  • Multiple containers from the same image each get their own private writable layer, so they never interfere with each other.
flowchart TB
    subgraph Image[Image - read-only]
        A[Base Layer]
        B[App Layer]
        C[Config Layer]
    end
    subgraph Container[Container]
        D[Writable Layer]
    end
    A --- B --- C --- D
    D -.-> E[Container processes write here]

A Container Is Just a Process

Here is the key insight that surprises most beginners: a container is not a virtual machine. There is no hypervisor, no guest operating system, and no heavy boot process.

A container is simply a process on your machine — usually one or a few processes started from the command defined in the image (like CMD ["node", "app.js"]). What makes it special is that it runs with its own isolated environment, created using two Linux kernel features:

  • Namespaces — isolation of what the process can see.
  • cgroups — control over what the process can use.

Because containers share the host kernel instead of running their own, they start in seconds and use far fewer resources than virtual machines.

Namespaces: Isolating the Process

Namespaces give each container its own private view of the system. According to the source document, namespaces isolate:

  • Process IDs — a container sees its own PID space (PID 1 inside, unrelated to the host).
  • Hostname — each container can have its own hostname and domain name.
  • Network — each container gets its own network stack, interfaces, and routing tables.
  • Mount points — each container has its own filesystem layout.
  • Shared memory — inter-process communication (IPC) resources are isolated per container.
Namespace What it isolates
PID Process IDs and the process tree
Network Network interfaces, stacks, ports
Mount Filesystem mount points
UTS Hostname and domain name
IPC Shared memory and inter-process communication

cgroups: Controlling Resource Usage

If namespaces answer "what does the process see?", cgroups (control groups) answer "how much can the process use?"

Cgroups are the kernel mechanism that controls CPU, RAM, and I/O usage for each container. When you run a container, Docker places its processes into a dedicated cgroup, then applies the limits you requested.

docker run --cpus=0.5 --memory=512m myapp:latest
Resource Controlled by cgroups
CPU CPU shares and quotas
RAM Memory limits
I/O Block device I/O limits

This is what stops a runaway container from exhausting the entire host — and it is also what lets you pack many containers onto one machine safely.

Diagram of Docker's interfaces with the Linux kernel

The diagram above shows how Docker and its execution backends (such as libcontainer) sit on top of the Linux kernel, using cgroups, namespaces, and related kernel features to provide isolation.

Networking: veth, docker0, and iptables

A container is isolated, but it still needs to reach the outside world and receive traffic. Docker handles this in two steps.

The Virtual Ethernet Interface

When a container starts, Docker gives it a virtual Ethernet interface (a veth pair). By default, one end of that interface is connected to the docker0 bridge — a virtual switch that Docker creates on the host. All containers attached to docker0 can talk to each other, and the bridge provides a path to the host's network.

Port Mapping with iptables

If you use the -p flag, Docker sets up iptables rules to forward traffic. For example, -p 8080:80:

  1. Docker binds host port 8080 to the container's port 80.
  2. Docker creates iptables rules in the NAT table.
  3. When a packet arrives on the host at port 8080, iptables rewrites its destination and forwards it to the container's IP on docker0.
sequenceDiagram
    participant User as User request
    participant Host as Host: port 8080
    participant FW as iptables (NAT)
    participant Bridge as docker0 bridge
    participant Container as Container: port 80
    User->>Host: GET / on localhost:8080
    Host->>FW: Packet arrives on port 8080
    FW->>Bridge: DNAT to container IP:80
    Bridge->>Container: Deliver via veth interface
    Container-->>User: Response

The result: from the outside, your app simply appears to be running on port 8080 of the host.

The Docker Daemon and the REST API

Two distinct components run Docker: the daemon and the CLI.

The Docker daemon, called dockerd, runs in the background on your host. It is the engine that actually does the work: handling builds, managing containers, images, volumes, and networks.

The Docker CLI (docker) is only a client. It does not build images or run containers itself — it sends commands to the daemon using a REST API over a Unix socket or TCP.

# The CLI talks to dockerd over a Unix socket by default
docker ps

This client-server split is why you can run Docker commands on your machine while the daemon runs elsewhere (for example, on a remote server) just by changing the endpoint the CLI connects to.

Caution: Anyone with access to the Docker daemon effectively has root access to the host. Never expose the daemon's TCP socket to untrusted networks — it is a well-known way to get your machine compromised.

Volumes: Persisting Data Beyond the Container

Because container writes go into the writable layer, they are temporary. If you delete the container, the changes are gone — unless you saved them to a volume or an image.

Volumes solve the persistence problem. They live outside the container layer and are stored on the host in /var/lib/docker/volumes. Because they are independent of the container's lifecycle, they survive container restarts — and even container deletion.

# Create a volume and mount it into a container
docker volume create mydata
docker run -v mydata:/data myapp:latest

This is how you persist databases, user uploads, logs, and any other data that must outlive a container. When a new container starts from the same image, it simply mounts the volume again and picks up right where the old one left off.

Content-Based Hashing: Reusable and Cacheable Layers

The final piece of the puzzle is how Docker identifies and shares layers.

Docker uses content-based hashes for layers. Each layer's content is hashed, and that hash is used as the layer's identity. This has three powerful consequences:

  1. Reusable — if two images contain a byte-identical layer, that layer is stored once and shared.
  2. Cacheable — during docker build, if the current instruction's inputs produce the same hash as a cached layer, Docker skips the work.
  3. Easy to share — registries and clients refer to layers by hash, so integrity is guaranteed.

Only What Is Missing Gets Uploaded

This hashing also makes docker push efficient. When you push an image, Docker checks which layers are already in the registry and only uploads what is missing.

If your new image only changed one line of source code, the rebuilt layer — and only that layer — is pushed. Everything else is reused from the registry.

flowchart LR
    A[New image with 5 layers] --> B{Registry check}
    B -->|Layer hashes 1-4 already exist| C[Skip upload]
    B -->|Layer 5 is new| D[Upload layer 5 only]
    C --> E[Image becomes available]
    D --> E

A Real-World Walkthrough

Let's put all of this together with a concrete example. Suppose you have a small Node.js application:

myapp/
├── Dockerfile
├── package.json
└── app.js

Step 1 — Build. You run docker build -t myuser/myapp:1.0 .. The daemon reads the Dockerfile line by line, treats the current folder as the build context, and creates one layer per instruction. Each layer is stored as a compressed file in Docker's storage, and the layers are joined into a single filesystem using OverlayFS.

Step 2 — Push. You run docker push myuser/myapp:1.0. Docker computes content hashes for all layers and asks the registry which ones already exist. If a previous version of your app shared the base and dependency layers, only the changed layers are uploaded.

Step 3 — Run. You run docker run -d -p 8080:3000 myuser/myapp:1.0. The daemon adds a writable layer on top of the image, creates namespaces to isolate the container's PIDs, network, mount points, hostname, and IPC, applies cgroups limits for CPU, RAM, and I/O, and attaches a virtual Ethernet interface to the docker0 bridge. The -p 8080:3000 flag triggers iptables rules that forward traffic from host port 8080 to the container's port 3000.

Step 4 — Persist. If your app writes to /data, you mount a volume so the data survives restarts:

docker run -d -p 8080:3000 -v mydata:/data myuser/myapp:1.0

Deleting the container later removes the writable layer, but mydata in /var/lib/docker/volumes remains intact.

Conclusion

Underneath the friendly docker command lies a well-designed stack of Linux kernel features:

  • docker build reads your Dockerfile line by line and produces image layers stored as compressed files.
  • OverlayFS stacks those layers into a single container filesystem.
  • docker run adds a writable layer, and the container runs as an ordinary process — isolated by namespaces and limited by cgroups.
  • Virtual Ethernet + docker0 + iptables connect the container to the network and forward published ports.
  • dockerd orchestrates everything, while the CLI talks to it over a REST API on a Unix socket or TCP.
  • Volumes persist data outside the container lifecycle, and content-based hashing makes layers reusable, cacheable, and cheap to push.

Once you understand these pieces, Docker stops feeling like magic and becomes a set of familiar, predictable mechanisms you can reason about — which is exactly what you need when debugging builds, diagnosing networking issues, or designing efficient CI/CD pipelines.

Key Takeaways

  • A container is not a virtual machine — it is a process running with an isolated environment on the host kernel.
  • Each Dockerfile instruction creates an image layer, stored as a compressed file in Docker's storage.
  • OverlayFS, a union filesystem, stacks all layers into one unified container filesystem.
  • docker run adds a writable layer on top of the read-only image; container writes are temporary by default.
  • Namespaces isolate what a container sees (PIDs, hostname, network, mounts, IPC), while cgroups control what it can use (CPU, RAM, I/O).
  • Networking works through a virtual Ethernet interface, the docker0 bridge, and iptables rules for -p port mapping.

Frequently Asked Questions

Q1: Is a Docker container a lightweight virtual machine?

No. A container is a regular process on your host that is isolated with Linux namespaces and cgroups. Unlike a VM, it shares the host kernel and has no guest operating system, which is why it starts in seconds and uses minimal resources.

Q2: Why does each line in a Dockerfile create a layer?

Layers are the unit of reuse and caching. Storing each instruction as a separate layer means unchanged layers can be cached during builds, shared across images, and skipped during pushes — only what actually changed gets rebuilt or transferred.

Q3: What happens to data written inside a running container when I delete it?

It is lost. Changes are written to the temporary writable layer on top of the image, so deleting the container destroys them unless the data was written to a volume (stored under /var/lib/docker/volumes) or committed to an image.

Q4: How does docker run -p 8080:80 forward traffic to the container?

Docker sets up iptables NAT rules that rewrite packets arriving on host port 8080 and forward them to the container's port 80 through the docker0 bridge and the container's virtual Ethernet interface.

Q5: Why does pushing an image upload so little data?

Docker identifies each layer by a content-based hash. When pushing, it queries the registry to see which layer hashes already exist and only uploads the layers that are missing, so unchanged layers are reused instead of re-uploaded.
